IHF High Concentration Sulfuric Acid Transfer Pump PTFE Lined Pump

    Buy cheap IHF High Concentration Sulfuric Acid Transfer Pump PTFE Lined Pump from wholesalers

    Buy cheap IHF High Concentration Sulfuric Acid Transfer Pump PTFE Lined Pump from wholesalers
    • Buy cheap IHF High Concentration Sulfuric Acid Transfer Pump PTFE Lined Pump from wholesalers
    • Buy cheap IHF High Concentration Sulfuric Acid Transfer Pump PTFE Lined Pump from wholesalers
    • Buy cheap IHF High Concentration Sulfuric Acid Transfer Pump PTFE Lined Pump from wholesalers
    • Buy cheap IHF High Concentration Sulfuric Acid Transfer Pump PTFE Lined Pump from wholesalers

    IHF High Concentration Sulfuric Acid Transfer Pump PTFE Lined Pump

    Ask Lasest Price
    Brand Name : Gempump
    Model Number : IHF25-20-125
    Certification : ISO9001
    Price : 500USD/Set
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 Sets per month
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    IHF High Concentration Sulfuric Acid Transfer Pump PTFE Lined Pump

    IHF High Concentration Sulfuric Acid Pump PTFE Lining Pump Acid Sulfuric Pump

    IHF sulfur water treatment acid circulation salt water pump

    Operating Range
    Flow: 7m3/h-400m3/h; 31 GPM-1770 GPM
    Head: 22m-80m; 22 GPM to 260 feet
    Temperature: -20 °C to +160 °C;-4 to 320°F
    IHF Acid Pump PTFE Lining Pump Application:
    Corrosive, pure and contaminated media in the chemical, pharmaceutics and petrochemical industries, in metal processing, waste water treatment;
    When stainless steel is not sufficiently resistant;
    An alternative to expensive haste alloy, titanium alloy pumps;
    When anti-adhesive surfaces are important.

    Working principle:
    Centrifugal
    Casing Material:
    FEP/PFA/PTFE Lining
    Maximum flow rate:
    400 m3/h
    Maximum Head:
    80 m
    Maximum Power:
    110 Kw

    Pumping Liquid

    1. Acid and caustic liquid
    2. Oxidizer corrosive liquids
    3. Difficult-to-seal liquids
    4. Sulfuric acid
    5. Hydroelectric acid
    6. Nitric acid
    7. Acid and lye
    8. Nitromuriatic acid

    IHF PTFE Chemical Acid Centrifugal Pump Parameters:
    Pump Model
    capacity(m³/h)
    head(m)
    power(kw)
    inlet/outlet(mm)
    IHF32-25-125
    5
    20
    1.5
    32/25
    IHF32-25-125A
    4.5
    16
    1.1
    32/25
    IHF32-25-160
    5
    32
    2.2
    32/25
    IHF32-25-160A
    4.5
    28
    1.5
    32/25
    IHF40-32-125
    6.5
    20
    2.2
    40/32
    IHF40-32-125A
    5.6
    16
    1.5
    40/32
    IHF40-32-160
    6.5
    32
    2.2
    40/32
    IHF40-32-160A
    5.6
    28
    1.5
    40/32
    IHF50-32-125
    20
    12.5
    2.2
    50/32
    IHF50-32-125A
    11
    11
    1.5
    50/32
    IHF50-32-160
    12.5
    32
    4
    50/32
    IHF50-32-160A
    11.7
    28
    3
    50/32
    IHF50-32-200
    12.5
    50
    7.5
    50/32
    IHF50-32-200A
    11.7
    44
    5.5
    50/32
    IHF50-32-250
    12.5
    80
    11
    50/32
    IHF50-32-250A
    11.7
    70
    7.5
    50/32
    IHF65-40-200
    25
    50
    11
    65/40
    IHF65-50-125
    25
    20
    3
    65/50
    IHF65-50-125A
    22.3
    16
    2.2
    65/50
    IHF65-50-160
    25
    32
    5.5
    65/50
    IHF65-50-160A
    23.3
    28
    4
    65/50
    IHF65-50-200
    25
    50
    11
    65/50
    IHF65-50-200A
    23.3
    44
    7.5
    65/50
    IHF65-50-250
    25
    80
    11
    65/50
    IHF65-50-250A
    23.3
    70
    15
    65/50
    IHF80-65-125
    50
    20
    5.5
    80/65
    IHF80-65-125A
    45
    16
    4
    80/65
    IHF80-50-250
    50
    80
    30
    80/50
    IHF80-50-250A
    45
    70
    22
    80/50
    IHF100-80-125
    100
    20
    11
    100/80
    IHF100-80-125A
    89
    16
    7.5
    100/80
    IHF100-80-160
    100
    32
    15
    100/80
    IHF100-80-160A
    93.5
    28
    11
    100/80
    IHF100-65-200
    100
    50
    30
    100/65
    IHF100-65-200A
    93.6
    44
    22
    100/65
    IHF100-65-250
    100
    80
    45
    100/65

    FAQ

    Q:Can you supply pump qualified with ANSI and ASME standard?
    A:Yes, our pump compliant with ISO / ASME/ANSI standard.
    Q:How to customize pumps and mechanical seals ?
    A:Customers could send us application data, we will select suitable pump and seal types, or client could send us drawings, We are well in OEM and ODM.
    Q:How can I pay for my items? What is the payment you can provide?
    A:Usually by T/T, 30% down payment once PI confirmed, the balance will be paid after inspection and before shipment. L/C at sight
    Q:How long is warranty?
    A:1 year for main construction warranty.
    Q:How long is production lead time?
    A:Normally 7 days. If client need urgently, we have a huge spare parts stock, we could finish assembly and testing in 3-5 days.
    Q:What is the shipping terms you can provide?
    A:Depnends on customer's requirements, we can provide different transportantin terms, such as EXW, FOB, CIF.
    Q:Who is in charge of after-sales?
    A:Teflow has professional after sales service team, we will follow up the client's comments and suggest them good solutions. Solve client's problems and keeping the clients profit.
    Q:Who is in charge of maintenance?
    A:Local agent. If pump running has any problem on site, our local agent will arrival the plant within 24 hours
