Centrifugal Vertical Submersible Sand Suction Slurry Pump For Mining Floatation

The Gempump vertical sump pump excellence is embodied in the range of vertical Sump Pumps. Use a variety of speed and various modifications way, makes the pump in the best condition operation, long service life, high operating efficiency and can meet many kinds of poor transport conditions. It's widely used in the metallurgy, mining, coal, power, building materials, environmental protection and other departments.

1. SPGEM seires pumps are vertical and centrifugal slurry pumps, which work submerged to transport the abrasive and high-density slurry with large particles. The pumps have no need for any shaft seal and completely equivalent with the world famous pump sealing water. They can also run under the conditions of inadequate suction duty.Wet parts of SP(R)GEM pump are made of wear-resistant metal.

2. All parts of SP(R)GEM pump immersed in liquid are equipped with rubber liner, which is suitable for delivering the non-edge abrasive slurry.

3. Sump pump with extended-length shaft (L Series) is suitable to operate in deeper level in liquid. Guide bearing is added on this pump to make its operation more stable and flushing water should be fixed at the position of guide bearing.

Model No.:

e.g.
65QV(R)-SPGEM

65---Outlet diameter (mm)
QV---Frame type
SPGEM---Slurry pump submerged in sump

R---Rubber liner

Vertical Slurry Pump Materials:

Metal:

Wear-resistant metal: A61, A05, A07, A11, A01

Anti-abrasive, anti-corrosive metal: A49, A33

Anti- abrasive metal: A22, A23, A25

Other optional metals or alloys: Duplex stainless steel, stainless steel, nickel cast iron, brass, bronze, etc.

Nonmetal:

Anti-corrosive, anti-corrosive rubber: natural rubber(R26, R24, R55......);

Synthetic rubber(S01, S12, S21, S42......)

Ceramics

(Note: The materials could be changed according to the customer’s requirements. )

Centrifugal Vertical Submersible Slurry Pump Application :

KY type submerged and vertical slurry pumps are mainly applicable to transport abrasive, coarse particle,

high concentration slurry. They are widely used in metallurgy, mining, coal, electric power, building

materials, environmental protection and other departments.

Shijiazhuang ultimate technology solutions Co., Ltd is one over 10 years experienced pump manufacturer (established at 2010) in mining and mineral, power plant, dredging and dredge, hydraulic, irrigation, pulp transfer, chemical, construction, sea water and oil & gas transfer etc.; Gempump is the pump factory has its own pump selection & design, research and development team to assure provide you efficient, energy saving slurry pump, sand pump,water pump, diesel water pump, chemical pump,solar pump and irrigation pump in selection & design, use and maintenance program.

Gempump is the pump factory approved by ISO9001, ISO14001 and OHSAS18001. We also have the certificate of CE. Our factory is over 50,000 square meters with the professional engineer over 20. The Max casting parts weight we could do one time is 7 tons. And we have capacity to produce 600 tons per month and with the heat treatment furnace dimension 6mx5.5mx2.5m. The Max parts we could machine is 6.4 meters and we have capacity to assemble the pump over 1800mm and our cranes capacity is 30 tons.Strong , experienced technical personnel is the powerful guarantee for quality products of slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps.

Gempump technical team set up five R & D teams: hydraulic engineering, water pump structure, new materials research and development, casting, molding etc. Except the commonly used CAD and other design software, the technical teams also use CAPP computer-aided industrial design and CFD hydraulic design software. They combine years of experience in the practical application of the products, repeated use of water conservancy GIS, MIS software and simulation analysis system software demonstrated, calculations, the theoretical calculations product of slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps are accurate and consistent with the actual performance. It allowing users to meet the needs while significantly reducing the investment costs, improves Gempump's strong core competitiveness.Gempump products include slurry pump, sewage pump, water pump, acid resistant or chemical pump, irrigation pumps, fire pumps,solar pump and other products exported to over 90 countries all over the world.

The application covers many fields, such as mining and mineral processing, dredger, tailings transportation, mining, steel, desulfurization pump, boiler feed water, construction, irrigation, water conservancy facilities, sewage treatment, drainage and water supply. In the era of rapid development of science and technology, Gempump team take the entrepreneurial spirit "excellence and constant product quality, brand known worldwide and Credit-based", business purpose "the achievements of create brand enterprise and industry pioneer", to help you out and provide quality & cheap innovative products!
