    2 Inch Vertical End Suction Centrifugal Pump Three Phase sewage booster pump

    Ask Lasest Price
    Brand Name : Gempump
    Model Number : ISG40-160
    Certification : ISO9001 CE
    Price : 1000 USD/SET
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 1000 SET/Month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    2 Inch Vertical End Suction Centrifugal Pump Three Phase sewage booster pump

    2 Inch Three Phase Vertical Inline Sewage Booster Pipeline Centrifugal Pump

    ISW series pumps,designed in ac-cordance with ISO2858 standard,are single-stage single-suction horizontal centrifugal pumps featured by inte-grated simple construction for less space, easy installation, smooth op-eration with less noise and free of daily maintenance due to the intro-duction of high quality mechanical seals and closed coupling.

    Vertical Inline Sewage Pump Features
    1. Integrated horizontal construction and smooth operation with closed coupling for space and cost saving.
    2. Low noise and Leak proof operation with mechanical seals of hard alloy materials.
    3. Vent valve designed on pump cover and water release at pump bottom, pressure detecting holes at flange inlet and outlet for on-line operation monitor.
    4. Working pressure up to 1.6Mpa.

    4 types of ISW series pumps are available for different applications, namely:
    ISW:for application of clean water or similar liquids within the temperature range of 0 ~ 80ºC, for instance cold/hot water circulation for air conditioning systems, water supply for high build- ings, water boosting for fire fighting systems, long distance water delivery, process circulation
    boost for industrial production, sprinkling irrigation for gardens etc..

    1. ISWR:for pumping of hot water (up 120ºC) circulating in greenhouse, boiler, bathroom and other HVAC systems. Also applicable to circulation boost of non-corrosive hot water in various in-dustries.

    2. ISWH:for pumping and boosting of various kinds of corrosive liquids (≤120ºC)in industries like chemical, environment protection, foodstuff and brewery, pharmacy, papermaking and textiles etc..

    3. ISWB:for pumping of non-corrosive oil and petrochemicals or any other flammable and explosive liquids (viscosity<120mm 2 /s) within the temperature range of -20 ~ 120ºC

    Performance Data
    Capacity Range:1.5 ~ 1203m 3 /hr
    Head Range:8 ~133m
    Speed:1450rmp/2900rpm
    Max. working pressure: 1.6Mpa
    Suction pressure: up to 1.0Mpa

    2 Inch Vertical End Suction Centrifugal Pump Three Phase sewage booster pump

    2 Inch Vertical End Suction Centrifugal Pump Three Phase sewage booster pump

    specification:

    Model
    Flow(m3/h)
    Head(m)
    Power(kw)
    Outlet(mm)
    Voltage(v)
    Speed(r/min)
    20-160
    2.5
    32
    1.1
    20
    380
    2900
    25-125
    4
    20
    0.75
    25
    380
    2900
    25-160
    4
    32
    1.5
    25
    380
    2900
    32-125
    4.5
    20
    0.75
    32
    380
    2900
    40-100
    6.3
    32
    2.2
    40
    380
    2900
    40-125
    6.3
    20
    1.1
    40
    380
    2900
    40-200
    6.3
    80
    7.5
    40
    380
    2900
    50-100
    12.5
    12.5
    1.1
    50
    380
    2900
    50-125
    12.5
    20
    1.5
    50
    380
    2900
    50-160
    12.5
    32
    6
    50
    380
    2900
    50-250
    12.5
    80
    11
    50
    380
    2900
    65-125
    25
    12.5
    3
    65
    380
    2900
    65-160
    25
    20
    4
    65
    380
    2900
    65-250
    25
    50
    15
    65
    380
    2900
    80-125
    50
    20
    5.5
    80
    380
    2900
    80-160
    50
    32
    7.5
    80
    380
    2900
    80-250
    50
    80
    22
    80
    380
    2900
    80-350
    50
    150
    55
    80
    380
    2900
    100-125
    100
    20
    11
    100
    380
    2900
    100-200
    100
    50
    22
    100
    380
    2900
    125-100
    160
    12.5
    11
    125
    380
    2900
    125-160
    160
    32
    22
    125
    380
    2900
    125-250
    160
    80
    55
    125
    380
    2900
    150-125
    160
    20
    15
    150
    380
    2900
    150-200
    160
    50
    37
    150
    380
    2900
    200-270
    400
    80
    132
    200
    380
    2900
    200-330
    400
    128
    220
    200
    380
    2900
